DVR

MT22-508S4-336A

■ 製品シリーズ : Tシリーズ


■ チャンネル : 8ch


■ 外形 : Lite


■ HDD Bay : 2個


■ Rec. performance : 2MP@Full

Video
Input8 BNC
Input Resolution8MP, 5MP, 4MP, 3MP, 2MP, 960H
Output1 HDMI, 1 VGA, 1 CVBS
Output Resolution4K, FHD, SXGA
Recording
Speed2MP : 30fps/ch
3MP, 4MP : 15fps/ch
5MP: 10fps
8MP: 7fps
Resolution8MP, 5MP, 4MP, 3MP, 2MP, 960H
CompressionH.265, H.264
Audio
Input8 RCA
Output1 HDMI, 1 RCA
Interface
Senser In / Out8 / 1 - NC / NO
USB2 x USB 2.0
PTZRS485 - Terminal Block
Network
InterfaceEthernet 10/100/1G
CompressionH.265, H.264
ResolutionMax. 4MP
System
OSEmbedded Linux (Built-in Flash Memory)
Pre / Post-Alarm5sec / 5sec~5min
Recording ModeContinuous, Event, Schedule
Data SearchSmart, Panorama, Calendar, Multi Day / Time, Event, Go to Time
Backup InterfaceUSB, Network
Backup TypeVideo(RMS, AVI), Capture(JPEG), Log List, Setup Data
Alarm ActionBuzzer, PTZ Preset, E-mail, Relay, Spot, Event Popup, Callback, Push
User15 Users (Admin, User1 ~ User14)
Network ViewerNetus, VMS, Web Viewer, Mac Viewer, NETUS-Eyes(iOS, Android)
ONVIFONVIF Profile T
Storage
Primary / Enternal2 HDD
General
Size (W x D x H)378 x 50 x 340 mm
Temp / Humidity5 ~ 40 ℃ / 10 ~ 80%
Power Supply12V / 5A
Power
Consumption
60 Watts

MT22-508S4-336A_사양서.pdf (307.2K)
