KO11-0808S-323A
Video | |
Input | 8 IP |
Input Resolution | Max. 4K |
Output | 1 HDMI / 1VGA |
Output Resolution | Max. 4K |
Recording | |
Speed | 7.5fps/ch (4K), 30fps/ch (2MP) |
Resolution | Max. 4K |
Compression | H.265, H.264. JPEG |
Audio | |
Input | 1CH |
Output | 1CH |
Interface | |
Senser In / Out | 8 IN / 1 OUT |
USB | 2 Port(Front 1, Rear 1) |
PTZ | RS485 - Terminal Block |
Network | |
Interface | 1 x Ethernet 10/100/1G |
Compression | H.264 |
Speed | 7.5fps (4MP) |
Resolution | Max. 4MP |
System | |
OS | Embedded Linux 4.2 (Built-in Flash Memory) |
Pre / Post-Alarm | 5sec / 5sec~5min |
Recording Mode | Continuous, Event, Schedule |
Data Search | Calendar, Multi Day / Time, Event, Go to Time |
Backup Interface | USB, Network |
Backup Type | Video (RMS, AVI), Log List, Setup Data |
Alarm Action | Buzzer, PTZ Preset, E-mail, Event Popup, Push |
User | 15 Users (Admin, User1 ~ User14) |
Network Viewer | NETUS-Pro, NETUS-Lite (Windows, Mac), NETUS-Eyes (iOS, Android) |
ONVIF | ONVIF Profile S |
Storage | |
Primary / Enternal | 1 HDD |
General | |
Size (W x D x H) | 300 x 227 x 53 mm |
Temp / Humidity | -10℃ ~ 50 ℃ / 10% ~ 90% |
PoE | 8 PoE, 802.3 at/af |
Power Supply | 48V / 1.5A |
Power Consumption | 96W |
[이 게시물은 最高経営責任者님에 의해 2024-09-04 14:46:06 NVR에서 복사 됨]
KO11-0808S-323A.pdf (286.7K)
