IPカメラ

VBO1-NMF8-NS

■ 製品シリーズ : Oシリーズ


■ カテゴリ : Full Color


■ 外観形態 : Dome


■ 解像度 : 8MP


■ レンズ形態 : Motorized

Camera
Image Sensor1/2.8" Progressice Scan CMOS
Effective Pixels8MP 3840(H)×2160(V)
Min. IlluminationColor 0.007lux @ F1.0(AGC ON) ;   B/W 0 lux @ IR ON
Shutter Speed1/5s to 1/20,000s
Lens
Type / Focal LengthMotorized / 2.8mm - 12mm
Filed of View(FOV)H: 107° to 34°, V: 56° to 19°, D: 129° to 39°
ApertureF1.2
Illuminator
Light TypeIR LED, Warm Light, Red/Blue Light
Range(IR/WARM)Up to 25m / 20m
Video
1st stream8MP(3840x2160), 5MP(2592x1944, 3072x1728), 4MP(2592x1520), 3MP(2304x1296),
1080P(1920x1080), 960P(1280*960), 720P(1280x720),
2nd stream720P(1280x720), VGA(640x480), QVGA(320x240)
3rd streamVGA(640x480), QVGA(320x240)
Compression H.265 / H.264
Video Quality Ajustment Full Color Mode / Day&Night Mode / Schedule
Bitrate ControlVBR / CBR
Audio
Sampling Rate8k
CompressionG.711ulaw / G.711alaw
Bitrate64kbps
Network
APIONVIF (Profile S, G, T)
ProtocolsTCP/IP, HTTP, DHCP, DNS, DDNS, RTP/RTSP, SMTP, NTP, UPnP, SNMP, HTTPS, FTP
SecurityIP address filter; complicated password; Authenticated username and password
Day & NightYes
WDRYes
Image Enhancement3D DNR, White Balance
Image SettingsFull Color Mode / Day&Night Mode / Schedule
Interface
EthernetRJ45 (10/100BASE-T)
On-Board StorageMicro SD slot, up to 256GB
Smart & Event
Smart featuresFace Recognition(FR) Human&Vehicle Detection(PD&VD)Perimeter Intrusion Detection(PID)
Line Crossing Detection(LCD) Cross Counting(CC)Stationary Object Detection(SOD)
Heat Map(HM)Crowd Density Detection(CD)Queue Length Detection(QD)
license Plate Detection(LPD)Rare Sound Detection(RSD)
EventsOff/On (8 Level)
General
MaterialMetal
Power D12V / POE (IEEE802.3af)
Operating Conditions-35~+60°C / less than  95% RH
Ingress Protection / IK codeIP67
VBO1-NMF8-NS 8MP_Full color_사양서.pdf (327.3K)
