TMT2-AMD8-TM

■ 製品シリーズ : Tシリーズ


■ カテゴリ : Day&Night


■ 外観形態 : Turret


■ 解像度 : 8MP


■ レンズ形態 : Motorized

Camera
Image Sensor1/2.7" Progressice Scan CMOS
Effective Pixels8MP (3840 × 2160)
Min. Illumination0.06Lux@F1.6(AGC ON), B/W 0 Lux IR on
Electronic ShutterAuto
Lens
Type / Focal LengthVarifocal / 2.8-12mm
Filed of View(FOV)H:106.6°-34.6°/  V:54.4°-19.5°/  D:132.9°-39.8°
ApertureF1.8-3.3
Illuminator
Light TypeIR
Range(IR/WARM)Up to 35m
Video & Event
Max. Framerate5MP: AHD/TVI: 5MP@20fps
4MP: AHD/CVI/TVI:P@25fps N@30fps
2MP: AHD/CVI/TVI:P@25fps N@30fps
CVBS: 960H
Day/Night Ext / Color / B/W
White BalanceATW
Image Enhancement2D DNR
AudioN/A
General
UTCACP(AHD Coax Protocol)
Power SupplyDC 12V
Power Consumption IR OFF ≤1W,IR ON ≤4W
Operating Temp.-30 °C to 55 °C
Ingress Protection / IK codeIP66
TMT2-AMD8-TM 8MP.pdf (217.4K)
