NVR

MX91-0808KS

■ 제품 시리즈 : X 시리즈


■ 채널 : 8채널


■ 외형 : Lite


■ PoE : 8PoE


■ HDD Bay : 1개

Video
Input 8 IP
Input Resolution Max. 4K
Output 1 HDMI
Output Resolution Max. 4K
Recording
Speed 7.5fps/ch (4K), 30fps/ch (2MP)
Resolution Max. 4K
Compression H.265, H.264. JPEG
Audio
Input 1CH
Output 1CH
Interface
Senser In / Out 4 IN / 1 OUT
USB 3 Ports (Front 2, Rear1)
PTZ RS485 - Terminal Block
Network
Interface 2 x Ethernet 10/100/1G
Compression H.265
Speed 7.5fps (4MP)
Resolution Max. 4K
System
OS Embedded Linux 4.2  (Built-in Flash Memory)
Pre / Post-Alarm 5sec / 5sec~5min
Recording Mode Continuous, Event, Schedule
Data Search Calendar, Multi Day / Time, Event, Go to Time
Backup Interface USB, Network
Backup Type Video(RMS, AVI), Capture(JPEG), Log List, Setup Data
Alarm Action Buzzer, PTZ Preset, E-mail, Event Popup, Push
User 15 Users (Admin, User1 ~ User14)
Network Viewer NETUS-Pro, NETUS-Lite (Windows, Mac), NETUS-Eyes (iOS, Android)
ONVIF ONVIF Profile S
Storage
Primary / Enternal 1HDD
General
Size (W x D x H) 340 x 60 x 300 mm
Temp / Humidity 5 ~ 40 / 10% ~ 80%
PoE 8PoE
Power Supply 48V, 1.5A
Power
Consumption
72W
MX91-0808KS.pdf (317.4K)
